Johnny Lucky PSU Lemon List
PC Power Supply Problems and Issues
The Johnny Lucky power supply lemon list identifies psu's to avoid. The PSU Lemon List includes descriptions of problems found and links to the hardware reviews that discovered the psu problems, issues, and flaws.
To find a high quality power supply that is safe, stable, and reliable please check the PSU Database
NOTICE: - Only brands and models that were reviewed and tested by competent hardware review sites are listed. There may be additional brands and models that might qualify for the lemon list but they are not included because they were not reviewed or subjected to rigorous testing.
|
|
| ATX 3.XX SERIES POWER SUPPLIES - UPDATE CURRENTLY IN PROGRESS!
|
| Asus |
| Model |
Watts |
Problems and Issues |
Reviews |
| ROG Strix Platinum |
500 |
Not fully compatible with ATX 3.1 standard. 12V rail transient response tests needs improvement. Trip thresholds (OCP) of the side rails must be adjusted. Mediocre transient response on the 3.3V rail. Hold-up time of the power OK signal is equal to the total hold-up time of the power supply. No protection mechanism in the event of a fan failure. Increased standby power consumption (Vampire Power). Distance between SATA connectors is less than 150mm. Conspicuous unclean soldering marks on the back of the PCB! |
Igor's Lab (DE) |
| Please read the power supply reviews for detailed descriptions of problems and issues.
|
| Equites |
| Model |
Watts |
Problems and Issues |
Reviews |
| T500 |
500 |
Power supply does not meet any safety standards. For the main 12 Volt line there are only 168 watts. Workmanship of the power supply is even worse. Container of dirt in psu! |
Benchmark (PL) |
| Please read the power supply reviews for detailed descriptions of problems and issues.
|
| Gigabyte |
| Model |
Watts |
Problems and Issues |
Reviews |
| UD1000GM PG5 |
850 |
Does not meet ATX 3.0 standards, Increased noise output, Overall performance needs boosting, Low quality Lelon caps on the secondary side, no bypass relay supporting the NTC thermistor, Not tight load regulation on the minor rails, Did not pass the 180% and 160% transient tests for ATX12V v3.0, High inrush current with 230V, Lower than 16ms power ok signal, Above 0.1W vampire power, No option to toggle off the semi-passive operation, Small distance between 4-pin Molex connectors, Two EPS connectors on the same cable |
AnandTech
Hardware Busters
Techpowerup
|
| Please read the power supply reviews for detailed descriptions of problems and issues.
|
| OCPC |
| Model |
Watts |
Problems and Issues |
Reviews |
| Energy II |
850 |
Only two Japanese capacitors, the rest are Chinese capacitors; 3.3V rail control exceeds 5%; 3.3V Rail Ripple Exceeds ATX Standard; Poor quality electronics; Poor quality cables; Sticker on the grill falls off; Bridge rectifiers reach high temperatures; Very low efficiency, especially in low load tests; Low power reserve; OCP protection threshold on 5 V rail too low |
IT Hardware (PL) |
| Please read the power supply reviews for detailed descriptions of problems and issues.
|
| Thermaltake |
| Model |
Watts |
Problems and Issues |
Reviews |
| Toughpower GF A3 |
750 |
Fake 80 PLUS Badge; died during the protection features evaluation; protection feature settings are wrong; Low overall performance; Loose load regulation; Mediocre transient response; Increased ripple at 5V; Both EPS on the same cable can cause trouble; Lower than 70% efficiency with a 2% load; APFC converter needs tuning for higher PF readings; Low 5VSB efficiency at 230V; Above 0.1W standby power at 230V |
Hardware Busters |
| Please read the power supply reviews for detailed descriptions of problems and issues.
|
| ATX 2.XX SERIES POWER SUPPLIES HAVE BEEN DELETED - REPLACED BY ATX 3.XX IN 2022 |
